| Price | : | To be announced |
| Status | : | Up Comming |
| Brand | : | Asus |
| Product Code | : | H470-Plus |
| General Information | ||
| Model | Asus Prime H470-Plus | |
| Supported Processor | Intel® Socket 1200 for 10th Gen Intel® Core™, Pentium® Gold and Celeron® Processors | |
| Chipset | Intel® H470 | |
| Socket | 1200 | |
| BIOS | 128 Mb Flash ROM, UEFI AMI BIOS | |
| Form Factor | ATX Form Factor 12-inch x 9.2 inch | |
| Memory Information | ||
| Memory Types | DDR4 | |
| Channel | Dual-Channel | |
| Slot | 4 x DIMM | |
| Supported Bus Speed | 128GB, DDR4 2933/2800/2666/2400/2133 MHz | |
| Maximum Memory | 128GB | |
| Graphics Information | ||
| Graphics | * 1 x DisplayPort 1.4 * 1 x HDMI 1.4b * Graphics specifications may vary between CPU types. * Support DisplayPort 1.4 with max. |
|
| Expansion Slots | ||
| PCI | * 1 x PCIe 3.0 x16 (x16 mode)
* 1 x PCIe 3.0 x16 (x4 mode)
* 4 x PCIe 3.0 x1 |
|
| Storage Information | ||
| M.2 | * 1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode) * 1 x M.2 Socket 3, with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE |
|
| SATA | 6 x SATA 6Gb/s port(s) | |
| RAID | Support Raid 0, 1, 5, 10 | |
| Connector Information | ||
| Internal Connectors | * 1 x CPU Fan connector(s) * 3 x Chassis Fan connector(s) * 1 x AIO_PUMP connector * 1 x Aura RGB Strip Headers * 1 x Addressable Gen 2 header(s) * 2 x USB 3.2 Gen 1(up to 5Gbps) 3.2 Gen 1 port(s) * 2 x USB 2.0 connector(s) support(s) * 1 x M.2 Socket 3 with M key * 1 x M.2 Socket 3 with M Key * 1 x M.2 with E key for Wi-Fi module * 1 x SPI TPM header * 6 x SATA 6Gb/s connector(s) * 1 x S/PDIF out header(s) * 1 x Thunderbolt header(s) * 1 x 24-pin EATX Power connector(s) * 1 x 8-pin EATX 12V Power connectors * 1 x Front panel audio connector(s) (AAFP) * 1 x Clear CMOS jumper(s) * 1 x System panel connector * 1 x COM port header |
|
| Port Information | ||
| PS/2 Por | 1 x PS/2 keyboard/mouse combo port(s) |
|
| USB Port | * 2 x USB 3.2 Gen 2 (1 x Type-A+1 x USB Type-C®)
* 2 x USB 3.2 Gen 1 Type-A
* 4 x USB 2.0 *2 |
|
| HDMI Port | 1 x HDMI | |
| LAN Port | * Realtek® RTL8111H
* 1 x LAN (RJ45) port(s) |
|
| Audio Port | 3 x Audio jack(s) | |
| Display Port | 1 x DisplayPort | |
| Operating System | ||
| Supported OS | Windows® 10 64-bit | |
| Warranty | ||
| Warranty | 03 Years Warranty | |
Asus Prime H470-Plus motherboard gives you the strong foundation you expect in your first form, in addition to the versatility of developing with your aspirations. We've put together all the cool stuff with basic planning and design in the latest Intel® Socket 1200 for 10th Gen Intel® Core™, Pentium® Gold and Celeron® Processors support, so you can benefit from industry-driven advances, including tuning of mechanical structures. Extensive cooling control, and lively locally available sound.
This Asus Prime H470-Plus motherboard comes with Intel® Socket 1200 for 10th Gen Intel® Core™, Pentium® Gold and Celeron® Processors, Socket LGA1200, 128 Mb Flash ROM, UEFI AMI BIOS, Form Factor, Dual-Channel 4 x DIMM DDR4 Maximum Memory 128GB, Supported Bus Speed DDR4 2933/ 2800/ 2666/ 2400/ 2133 MHz. In this Asus Prime H470-Plus motherboard, 1 x DisplayPort 1.4, 1 x HDMI 1.4b, Graphics determinations might fluctuate between CPU types, Support DisplayPort 1.4 with max. Expansion Slots are 1 x PCIe 3.0 x16 (x16 mode), 1 x PCIe 3.0 x16 (x4 mode), 4 x PCIe 3.0 x1. For storage functions are 1 x M.2 Socket 3, with M key, type 2242/ 2260/ 2280/ 22110 storage devices support (PCIE 3.0 x 4 mode), 1 x M.2 Socket 3, with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE), 6 x SATA 6Gb/s port(s), Support Raid 0, 1, 5, 10. 1 x 24-pin EATX Power connector(s), 1 x 8-pin EATX 12V Power connectors, 1 x SPI TPM header, 1 x Front panel audio connector(s) (AAFP), 3 x Chassis Fan connector(s), 1 x System panel connector.
This Asus Prime H470-Plus motherboard OS Support for Windows® 10 64-bit, You can enjoy a 03 Years Warranty. Purchase Motherboard from Original Store Ltd and get online conveyance at any side of Bangladesh.
