Gigabyte B450 AORUS PRO Wi-Fi AMD ATX Motherboard

B450 AORUS PRO Wi-Fi

* AMD Ryzen™ 2nd Generation processors

* AMD Ryzen™ with Radeon™ Vega Graphics processors

* AMD Ryzen™ 1st Generation processor

* AMD Ryzen™ 3rd Generation processor

* 2 x 128 Mbit flash

* Use of licensed AMI UEFI BIOS

* Support for DualBIOS™

* PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

DDR4

* 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz

* The DVI-D port does not support D-Sub connection by adapter.

* 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz

* Support for HDMI 2.0 version and HDCP 2.2.

* Actual support may vary by CPU.

* Maximum shared memory of 16 GB

* 1 x PCI Express x16 slot, running at x16 (PCIEX16)

* Actual support may vary by CPU.

* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.

(The PCIEX16 slot conforms to PCI Express 3.0 standard.)

* 1 x PCI Express x16 slot, running at x4 (PCIEX4)

* The PCIEX4 slot shares bandwidth with the PCIEX1_1 and PCIEX1_2 slots. The PCIEX4 slot operates at up to x2 mode when the PCIEX1_1/PCIEX1_2 slot is populated. The PCIEX4 slot operates at up to x4 mode when both of the PCIEX1_1 and PCIEX1_2 slots are empty.

* 1 x PCI Express x16 slot, running at x1 (PCIEX1_2)

* 1 x PCI Express x1 slot (PCIEX1_1)

(The PCIEX4 and PCIEX1 slots conform to PCI Express 2.0 standard.)

* 1 x M.2 Socket 1 connector for a wireless communication module (M2_WIFI)

* B450 AORUS PRO WIFI includes the wireless communication module.

* 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 3.0 x4/x2 SSD support) (M2A_SOCKET)

* 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 PCIe 3.0 x2 SSD support)(M2B_SOCKET)

* 1 x 24-pin ATX main power connector

* 1 x 8-pin ATX 12V power connector

* 2 x M.2 Socket 3 connectors

* 6 x SATA 6Gb/s connectors

* 1 x CPU fan header

* 1 x water cooling CPU fan header

* 2 x system fan headers

* 1 x system fan/water cooling pump header

* 1 x CPU cooler LED strip/RGB LED strip header

* 2 x digital LED strip headers

* 2 x digital LED strip power select jumpers

* 1 x RGB (RGBW) LED strip header

* 1 x front panel header

* 1 x front panel audio header

* 1 x S/PDIF Out header

* 1 x USB 3.1 Gen 1 header

* 2 x USB 2.0/1.1 headers

* 1 x Trusted Platform Module (TPM) header (2x10 pin, for the GC-TPM2.0 module only)

* 1 x Clear CMOS jumper

* 1 x USB Type-C™ port on the back panel, with USB 3.1 Gen 2 support

* 1 x USB 3.1 Gen 2 Type-A port (red) on the back panel

* 2 x USB 3.1 Gen 1 ports available through the internal USB header

* 4 x USB 2.0/1.1 ports available through the internal USB headers

* 4 x USB 3.1 Gen 1 ports on the back panel

* Realtek® ALC1220-VB codec

* High Definition Audio

* 2/4/5.1/7.1-channel

* Support for S/PDIF Out

* Support for Windows 10 64-bit

* Support for Windows 7 64-bit

* To support Windows 7 64-bit, you must install an AMD Pinnacle Ridge & Summit Ridge CPU.

03 Years Warranty
