| Price | : | To be announced |
| Status | : | Out of Stock |
| Brand | : | Gigabyte |
| Product Code | : | Z690 UD AX |
| General Information | ||
| Model | Z690 UD AX | |
| Brand | Gigabyte | |
| Supported Processor | * LGA1700 socket: Support for 12th Generation Intel® Core™ i9/ i7 / i5 processors * L3 cache varies with CPU |
|
| Chipset | Intel Z690 Express Chipset | |
| Socket | LGA1700 | |
| BIOS | * 1 x 256 Mbit flash * Use of licensed AMI UEFI BIOS * PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
|
| Form Factor | ATX Form Factor; 30.5cm x 24.4cm | |
| Memory Information | ||
| Memory Type | DDR4 / DDR5 | |
| Channel | Dual-channel | |
| Slot | 4 x DDR DIMM | |
| Supported Bus Speed | Support for DDR5 6000/ 5800/ 5600/ 5400/ 5200(O.C.) / 4800 / 4000 MHz memory modules | |
| Maximum Memory | Up to 128 GB | |
| Graphics Information | ||
| Graphics | * 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.1 version and HDCP 2.3. * Support native HDMI 2.1 TMDS compatible ports. * 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz * Support for DisplayPort 1.2 version and HDCP 2.3 |
|
| Expansion Slots | ||
| PCI | * 1 x PCI Express x16 slot, running at x16 (PCIEX16) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. * (The PCIEX16 slot conforms to PCI Express 5.0 standard.) * 1 x PCI Express x16 slot, running at x4 (PCIEX4) * 1 x PCI Express x16 slot, running at x1 (PCIEX1_4) * 2 x PCI Express x1 slots (The PCIEX4 and PCIEX1 slots conform to PCI Express 3.0 standard.) |
|
| Storage Information | ||
| M.2 | * 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2 SSD support) (M2A_CPU)
* 1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB)
* 1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe 4.0 x4/x2 SSD support) (M2Q_SB) |
|
| SATA | 6 x SATA 6Gb/s connectors | |
| RAID | Support for RAID 0, RAID 1, RAID 5, and RAID 10 | |
| Connector Information | ||
| Internal Connectors | * 1 x 24-pin ATX main power connector
* 1 x 8-pin ATX 12V power connector
* 1 x 4-pin ATX 12V power connector
* 1 x CPU fan header
* 1 x water cooling CPU fan header
* 3 x system fan headers
* 1 x system fan/water cooling pump header
* 2 x addressable LED strip headers
* 2 x RGB LED strip headers
* 3 x M.2 Socket 3 connectors
* 6 x SATA 6Gb/s connectors
* 1 x front panel header
* 1 x front panel audio header
* 1 x S/PDIF Out header
* 1 x USB Type-C® header, with USB 3.2 Gen 1 support
* 1 x USB 3.2 Gen 1 header
* 2 x USB 2.0/1.1 headers
* 1 x serial port header
* 2 x Thunderbolt™ add-in card connectors
* 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
* 1 x reset button
* 1 x reset jumper
* 1 x Q-Flash Plus button
* 1 x Clear CMOS jumper |
|
| Port Information | ||
| PS/2 | 1 x PS/2 keyboard/mouse port | |
| USB Port | * 1 x USB Type-C® port, with USB 3.2 Gen 2x2 support
* 1 x USB 3.2 Gen 2 Type-A port (red)
* 4 x USB 3.2 Gen 1 ports
* 4 x USB 2.0/1.1 ports |
|
| HDMI Port | 1 x HDMI Port | |
| Display | 1 x DisplayPort | |
| LAN Port | * 1 x RJ-45 port
* Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
|
| Audio Jack | 3 x audio jacks | |
| SMA Antenna | 2 x SMA antenna connectors (2T2R) | |
| Other Information | ||
| Wi-Fi | * Intel® Wi-Fi 6 AX201 (For PCB rev. 1.0)
* Intel® Wi-Fi 6 AX200 (For PCB rev. 1.1)
* WIFI a, b, g, n, ac, ax, supporting 2.4/5 GHz carrier frequency bands
* Intel® Wi-Fi 6E AX211 (For PCB rev. 1.2)
* WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
* BLUETOOTH 5.2
* Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate |
|
| Operating System | ||
| Supported OS | * Windows 11 64-bit
* Windows 10 64-bit |
|
| Warranty | ||
| Warranty | 3 Years Warranty | |
Gigabyte Z690 UD AX DDR5 Intel 12th Gen ATX Motherboard with the Z690 UD AX motherboard. Its delivery and dominant thermal design, are glorified with the complete memory overclocking technology to crown your PC with the best Alder Lake performance in all its gaming glory. It ensures maximum Turbo Boost and overclocking performance of Intel's new generation CPU. Buy Gigabyte Z690 UD AX DDR5 Intel 12th Gen ATX Motherboard at the best price in BD.
For more Motherboard information Please Check Gigabyte Motherboard, MSI Motherboard, Asus Motherboard, Esonic Motherboard, and Asrock Motherboard. And also If you Want to know more different type of IT Product information please Click here.
Gigabyte Z690 UD AX DDR5 Intel 12th Gen ATX Motherboard is Z690 UD AX ddr5. The Brand is Gigabyte. The Motherboard Supported Processor 12th Generation Intel Core i9 processors/ i7/ i5 processors. Chipset Intel Z690 Express Chipset. Socket LGA1700. BIOS 1 x 256 Mbit flash, Use of licensed AMI UEFI BIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0. Memory Type DDR4 / DDR5. Dual-channel. Slot 4 x DDR DIMM. Support for Support for DDR5 6000/ 5800/ 5600/ 5400/ 5200(O.C.) / 4800 / 4000 MHz memory modules. Maximum Memory Up to 128 GB. Graphics 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz, Support for HDMI 2.1 version and HDCP 2.3, Support native HDMI 2.1 TMDS compatible ports, 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz, Support for DisplayPort 1.2 version and HDCP 2.3. PCI 1 x PCI Express x16 slot, running at x16 (PCIEX16), For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. (The PCIEX16 slot conforms to PCI Express 5.0 standard.) 2 x PCI Express x16 slots, running at x4 (PCIEX4_1, PCIEX4_2),(The PCIEX4 slots conform to PCI Express 3.0 standard.) 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2 SSD support) (M2A_CPU). 2 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2 SSD support) (M2P_SB, M2Q_SB). 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 SATA and PCIe 4.0 x4/x2 SSD support) (M2M_SB). 6 x SATA 6Gb/s connectors. Support for RAID 0, RAID 1, RAID 5, and RAID 10. 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x 4-pin ATX 12V power connector 1 x CPU fan header 1 x water cooling CPU fan header 3 x system fan headers 1 x system fan/water cooling pump header 2 x addressable LED strip headers 2 x RGB LED strip headers 4 x M.2 Socket 3 connectors 6 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB Type-C® header, with USB 3.2 Gen 2 support 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 2 x Thunderbolt™ add-in card connectors 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) 1 x reset button 1 x reset jumper 1 x Q-Flash Plus button 1 x Clear CMOS jumper 1 x USB Type-C® port, with USB 3.2 Gen 2x2 support 2 x USB 3.2 Gen 2 Type-A ports (red) 3 x USB 3.2 Gen 1 ports 4 x USB 2.0/1.1 ports, 1 x HDMI port, 1 x DisplayPort, 1 x RJ-45 port, 2 x audio jacks, 1 x optical S/PDIF Out connector. Windows 11 64-bit * Windows 10 64-bit. Gigabyte Z690 UD AX DDR5 Intel 12th Gen ATX Motherboard has Three years warranty.
