| Price | : | To be announced |
| Status | : | Out of Stock |
| Brand | : | MSI |
| Product Code | : | B550M-A PRO |
| General Information | ||
| Model | MSI B550M-A PRO | |
| Brand | MSI | |
| Supported Processor | AMD Ryzen 5000 & 3000 Series desktop processors,3rd Generation | |
| Chipset | AMD B550 Chipset | |
| Socket | AM4 | |
| Form Factor | Micro MATX | |
| Memory Information | ||
| Memory Types | DDR4 | |
| Channel | Dual-channel | |
| Slot | 2x DDR4 memory slots | |
| Supported Bus Speed | * Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC * Supports DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400/ 4600+ MHz by A-XMP OC MODE |
|
| Maximum Memory | 64GB | |
| Graphics Information | ||
| Graphics | * 1x HDMI 1.4 port, supports a maximum resolution of 4096x2160 @60Hz12 * Support for HDMI™ 1.4 version, HDCP 1.4 & 2.3 * 1x DVI-D port, supports a maximum resolution of 1920x1200@60Hz1 * Maximum shared memory of 16 GB |
|
| Expansion Slots | ||
| PCI | * 1x PCIe 3.0 x1 slot 1 * 1x PCIe 4.0/3.0 x16 slot |
|
| Storage Information | ||
| M.2 | 1x M.2 slot (Key M) (from AMD Processor) | |
| SATA | * 4x SATA 6Gb/s ports * Supports SATA 6Gb/s |
|
| RAID | * Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices * Supports RAID 0 and RAID 1 for M.2 NVMe storage devices |
|
| Connector Information | ||
| Internal Connectors | * 1x 24-pin ATX main power connector * 1x 4-pin ATX 12V power connector * 4x SATA 6Gb/s connectors * 1x M.2 slots (M-Key) * 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports) * 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports) * 1x 4-pin CPU fan connector * 1x 4-pin system fan connectors * 1x Front panel audio connector * 2x System panel connectors * 1x Chassis Intrusion connector * 1xTPM module connector * 1x Clear CMOS jumper |
|
| Port Information | ||
| PS/2 Port | PS/2 Keyboard / Mouse Port | |
| USB Port | * AMD B550 Chipset * 2x USB 3.2 Gen 1 5Gbps ports are available through the internal USB 3.2 Gen 1 5Gbps connector * 6x USB 2.0 ports (2 Type-A ports on the back panel, 4 ports through the internal USB 2.0 connectors) * AMD Processor * 4x USB 3.2 Gen 1 5Gbps Type-A ports on the back panel |
|
| HDMI Port | 1 x HDMI | |
| LAN Port | 1x Realtek® RTL8111H Gigabit LAN controller | |
| Audio Port | * Realtek® ALC892/ALC897 Codec * 7.1-Channel High Definition Audio |
|
| Operating Systems | ||
| Supported OS | Support for Windows® 10 64-bit | |
| Warranty | ||
| Warranty | 3 Years Warranty | |
MSI B550M-A PRO AMD 3rd Gen AM4 Socket Micro ATX Motherboard. Its delivery and dominant thermal design, are glorified with the complete memory overclocking technology to crown your PC with the best Alder Lake performance in all its gaming glory. It ensures maximum Turbo Boost and overclocking performance of Intel's new generation CPU.
For more Motherboard information Please Check Gigabyte Motherboard, MSI Motherboard, Asus Motherboard, Esonic Motherboard, and Asrock Motherboard. And also If you Want to know more different type of IT Product information please Click here.
MSI B550M-A PRO AMD 3rd Gen AM4 Socket Micro ATX Motherboard. It is supported by Processor AMD Ryzen 5000 & 3000 Series desktop processors,3rd Generation, Chipset AMD B550 Chipset, Socket AM4, Form Factor Micro MATX. This is Memory Types DDR4, Channel Dual-channel, Slot 2x DDR4 memory slots, Supported Bus Speed, * Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC, * Supports DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400/ 4600+ MHz by A-XMP OC MODE, Maximum Memory 64GB. comes with standard Graphics such as 1x HDMI 1.4 port, supports a maximum resolution of 4096x2160 @60Hz, Supports HDMI 1.4 version, HDCP 1.4 & 2.3, 1x DVI-D port, supports a maximum resolution of 1920x1200@60Hz1, Maximum shared memory of 16 GB. B550M-A PRO MSI Motherboard Expansion PCI slot is 1x PCIe 3.0 x1 slot 1, 1x PCIe 4.0/3.0 x16 slot, 4 x SATA 6 GB/s connectors, and 2 x M.2 connector, Support for RAID 0, RAID 1, and RAID 10 devices, Supports RAID 0 and RAID 1 for M.2 NVMe storage devices also various Internal Connectors such as 1 x 24-pin ATX main power connector, 1 x front panel audio connector, 1 x 4 pin CPU fan header, etc. The MSI B550M-A PRO AMD Motherboard has 2 x USB 3.2 Gen 2 10Gbps, 6x USB 2.0 ports, 1 x HDMI port maximum resolution of 4096x2160 @24Hz, 1x Realtek RTL8111H LAN controller, and High Definition Audio with 7.1-Channel High Definition Audio. This MSI B550M-A PRO Motherboard Support for Windows 10 64-bit. You can enjoy 03 Years Warranty. Buy Motherboard from Original Store Ltd and get online delivery at any corner of Bangladesh.
