| Price | : | To be announced |
| Status | : | Out of Stock |
| Brand | : | MSI |
| Product Code | : | MEG B550 UNIFY |
| General Information | ||
| Model | MEG B550 UNIFY | |
| Brand | MSI | |
| Supported Processor | Supports AMD Ryzen 5000 & 3000 Series desktop processors (not compatible with AMD Ryzen 5 3400G & Ryzen 3 3200G) and AMD Ryzen 4000 G-Series desktop processors | |
| Chipset | AMD B550 Chipset | |
| Socket | AMD Socket AM4 | |
| Form Factor | ATX Form Factor 12 in. x 9.6 in. (30.4 cm x 24.4 cm) | |
| Memory Information | ||
| Memory Types | DDR4 | |
| Channel | Dual channel memory architecture | |
| Slot | 4x DDR4 memory slots | |
| Supported Bus Speed | Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC
AMD Ryzen 4000 G-Series processors support DDR4 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466/ 3600/ 3733/ 3866/ 4000/ 4133/ 4266/ 4400/ 4533/ 4600/ 4733/ 4866/ 5000/ 5100+ (Max. 5600) MHz by A-XMP OC MODE
3rd Gen AMD Ryzen processors supports DDR4 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466/ 3600/ 3733/ 3866/ 4000/ 4133/ 4266/ 4400/ 4533/ 4600/ 4733/ 4866/ 5000/ 5100+ MHz by A-XMP OC MODE
AMD Ryzen 4000 G-Series processors
1DPC 1R max speed 5100 MHz (QVL), Max. 5600 MHz
1DPC 2R max speed 4266 MHz
2DPC 1R max speed 4400 MHz
2DPC 2R max speed 3600 MHz
3rd Gen AMD Ryzen processors
1DPC 1R max speed 5100 MHz
1DPC 2R max speed 4000 MHz
2DPC 1R max speed 4000 MHz
2DPC 2R max speed 3600 MHz
Supports non-ECC UDIMM memory
Supports ECC UDIMM memory (non-ECC mode)
Supports un-buffered memory |
|
| Maximum Memory | 128GB | |
| Graphics Information | ||
| Graphics | 1 x HDMI 2.1 port, supporting a maximum resolution of 4096x2160 @120 Hz Supports 2-Way AMD CrossFire Technology | |
| Expansion Slots | ||
| PCI | AMD Processor 1x PCIe 4.0/ 3.0 x16 slot (PCI_E1) AMD B550 Chipset 1x PCIe 3.0 x16 slot (PCI_E4), supports x4 speed 2x PCIe 3.0 x1 slots (PCI_E2 & PCI_E3) |
|
| Storage Information | ||
| M.2 | 4x M.2 slots (Key M) | |
| SATA | 6x SATA 6Gb/s ports | |
| RAID | 0/1/10 | |
| Connector Information | ||
| Internal Connectors | 1x 24-pin ATX main power connector 2x 8-pin ATX 12V power connector 1x 6-pin PCIE power connector 6x SATA 6Gb/s connectors 4x M.2 slots (M-Key) 1x USB 3.2 Gen 2 10Gbps Type-C port 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports) 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 1x 4-pin CPU fan connector 1x 4-pin water-pump fan connector 6x 4-pin system fan connectors 1x Front panel audio connector 2x System panel connectors 1x Chassis Intrusion connector 1x 4-pin RGB LED connectors 2x 3-pin RAINBOW LED connectors 1x 3-pin CORSAIR LED connector 1x Clear CMOS jumper 1x Power button 1x Reset button |
|
| Port Information | ||
| USB Port | AMD Processor 4x USB 3.2 Gen 2 10Gbps ports(3 Type-A ports and 1 Type-C port) on the back panel AMD B550 Chipset 1x USB 3.2 Gen 2 10Gbps Type-C internal connector 2x USB 3.2 Gen 1 5Gbps ports are available through the internal USB 3.2 Gen 1 5Gbps connector 4x USB 2.0 ports on the back channel AMD B550 chipset + USB 2.0 Hubs 4x USB 2.0 ports are available through the internal USB 2.0 connectors |
|
| HDMI Port | 1 x HDMI 2.1 port, supporting a maximum resolution of 4096x2160 @120 Hz | |
| LAN Port | Realtek® 8125B-CG 2.5G LAN | |
| Audio Port | Realtek ALC1220P Codec 7.1-Channel High Definition Audio Supports S/PDIF output | |
| Special Features | ||
| Special Features | WIRELESS LAN & BLUETOOTH Intel Wi-Fi 6 AX200 The Wireless module is pre-installed in the M2_WIFI1 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz (160MHz) up to 2.4Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax Supports Bluetooth 5.1 |
|
| Operating Systems | ||
| Supported OS | Support for Windows® 10 64-bit | |
| Warranty | ||
| Warranty | 03 Years Warranty | |
MSI MEG B550 UNIFY AMD 3rd Gen AM4 ATX Motherboard helps users work smarter by delivering an efficient and productive experience. It is MSI MEG B550 UNIFY AMD Motherboard that let you manage speeds and temperatures for all your system and CPU fans.
For more Motherboard information Please Check Gigabyte Motherboard, MSI Motherboard, Asus Motherboard, Esonic Motherboard, and Asrock Motherboard. And also If you Want to know more different type of IT Product information please Click here.
MSI MEG B550 UNIFY AMD 3rd Gen AM4 ATX Motherboard comes with AMD Socket AM4, Supports AMD Ryzen 5000 & 3000 Series desktop processors (not compatible with AMD Ryzen 5 3400G & Ryzen 3 3200G) and AMD Ryzen 4000 G-Series desktop processors, Chipset AMD B550 with 30.5 cm x 24.4 cm ATX Form Factor. MSI MEG B550 UNIFY DDR4 Motherboard Maximum 128 GB DDR4 Dual Channel Memory, 4 x DDR4 DIMM sockets, Supported Bus Speed Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC, The AMD Ryzen 4000 G-Series processors supports DDR4 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466/ 3600/ 3733/ 3866/ 4000/ 4133/ 4266/ 4400/ 4533/ 4600/ 4733/ 4866/ 5000/ 5100+ (Max. 5600) MHz by A-XMP OC MODE, AMD Ryzen 3rd Gen processors supports DDR4 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466/ 3600/ 3733/ 3866/ 4000/ 4133/ 4266/ 4400/ 4533/ 4600/ 4733/ 4866/ 5000/ 5100+ MHz by A-XMP OC MODE, AMD Ryzen 4000 G-Series processors, 1DPC 1R max speed 5100 MHz (QVL), Max. 5600 MHz. MSI MEG B550 UNIFY Motherboard comes with standard Graphics such as 1 x HDMI 2.1 port, supporting a maximum resolution of 4096x2160 @120 Hz Supports 2-Way AMD CrossFire Technology. MEG B550 UNIFY MSI Motherboard Expansion PCI Slots is 1x PCIe 3.0 x1 slot 1, 1x PCIe 4.0/3.0 x16 slot, 6 x SATA 6 GB/s connectors and 4 x M.2 connector, Support for RAID 0, RAID 1, and RAID 10 devices, Supports RAID 0 and RAID 1 for M.2 NVMe storage devices also various Internal Connectors such as 1 x 24-pin ATX main power connector, 1 x front panel audio connector, 1 x 4 pin CPU fan header etc. The MSI MEG B550 UNIFY Motherboard has 2 x USB 3.2 Gen 2 10Gbps, 6x USB 2.0 ports, 1 x HDMI port maximum resolution of 4096x2160 @24Hz, Realtek® 8125B-CG 2.5G LAN, and High Definition Audio with 7.1-Channel High Definition Audio. Special features of this MSI motherboard are WIRELESS LAN & BLUETOOTH Intel Wi-Fi 6 AX200, In wireless module is pre-installed in the M2_WIFI1 (Key-E) slot 2.4GHz/ 5GHz (160MHz) up to 2.4Gbps, Supports MU-MIMO TX/RX. This MSI MEG B550 UNIFY AMD 3rd Gen AM4 ATX Motherboard Support for Windows 10 64-bit. You can enjoy 03 Years Warranty. Buy Motherboard from Original Store Ltd and get online delivery at any corner of Bangladesh.
