| Price | : | To be announced |
| Status | : | Out of Stock |
| Brand | : | Asus |
| Product Code | : | ProArt Z490 |
| General Information | ||
| Model | Asus ProArt Z490 | |
| Supported Processor | Intel® Socket 1200 for 10th Gen Intel® Core™, Pentium® Gold and Celeron® Processors * | |
| Chipset | Intel® Z490 | |
| Socket | 1200 | |
| BIOS | 128 Mb Flash ROM, UEFI AMI BIOS | |
| Form Factor | ATX Form Factor 12-inch x 9.2 inch | |
| Memory Information | ||
| Memory Types | DDR4 | |
| Channel | Dual Channel | |
| Slot | 4 x DIMM | |
| Supported Bus Speed | 4800/ 4600(O.C)/ 4500(O.C)/ 4400(O.C)/ 4266/ 4133/ 4000/ 3866/ 3733/ 3600/ 3466/ 3400/ 3333/ 3300/ 3200/ 3000/ 2933/ 2800/ 2666/ 2400/ 2133 MHz | |
| Maximum Memory | 128GB | |
| Graphics Information | ||
| Graphics | * 1 x DisplayPort 1.4 ** * 1 x HDMI 1.4b * Graphics specifications may vary between CPU types |
|
| Expansion Slots | ||
| PCI | * Intel® 10th Gen Processors * 2 x PCIe 3.0 x16 (x16 or dual x8) *1 * Intel® Z490 Chipset * 1 x PCIe 3.0 x16 (x4 mode) *2 * 2 x PCIe 3.0 x1 |
|
| Storage Information | ||
| M.2 | * 1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support * 1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support |
|
| SATA | 6 x SATA 6Gb/s port(s) | |
| RAID | Support Raid 0, 1, 5, 10 | |
| Connector Information | ||
| Internal Connectors | * 1 x CPU Fan connector(s) * 1 x CPU OPT Fan connector(s) * 3 x Chassis Fan connector(s) * 1 x AIO_PUMP connector * 2 x Aura RGB Strip Headers * 1 x Addressable Gen 2 header(s) * 1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) * 1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) Gen 1 port(s) * 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) * 1 x M.2 Socket 3 with M key, * 1 x M.2 Socket 3 with M key, * 6 x SATA 6Gb/s connector(s) * 1 x 24-pin EATX Power connector(s) * 1 x 8-pin EATX 12V Power connectors * 1 x Front panel audio connector(s) (AAFP) * 1 x System panel(s) (Chassis intrusion header is inbuilt) * 1 x Thermal sensor connector(s) * 1 x CPU OV * 1 x Clear CMOS jumper(s) * 1 x COM port header |
|
| Port Information | ||
| USB Port | * 4 x USB 3.2 Gen 2 Type-A
* 2 x USB 3.2 Gen 1 Type-A |
|
| HDMI Port | 1 x HDMI | |
| LAN Port | * Intel® I225-V 2.5Gb Ethernet
* 1 x LAN (2.5G) port(s) |
|
| Audio Port | 5 x Audio jack(s) | |
| Display Port | 2 x DisplayPort IN ports for Thunderbolt™ 3 | |
| Optical Drive | 1 x Optical S/PDIF out | |
| Operating System | ||
| Supported OS | Windows® 10 64-bit | |
| Warranty | ||
| Warranty | 03 Years Warranty | |
Asus ProArt Z490 CREATOR 10G motherboards give the strong establishment expected to your first form, in addition to versatility to develop with your aspirations. We have merged all the great stuff that is pressed into the most recent Build in 10th Gen Intel® Core™, Pentium® Gold and Celeron® Processors with the essential plan and designing, so you advantage from industry-driving advances, broad cooling controls, including mechanized framework tuning, and vivid installed sound.
For more Motherboard information Please Check Gigabyte Motherboard, MSI Motherboard, Asus Motherboard, Esonic Motherboard, and Asrock Motherboard. And also If you Want to know more different type of IT Product information please Click here.
Asus ProArt Z490 CREATOR ATX Motherboard accompanies 10th Gen Intel Core, Pentium Gold and Celeron Processors 1200 Socket, Build in Intel Z490 Chipset with 128 Mb Flash ROM, UEFI AMI BIOS, 12 inch x 9.2 inch ATX Form Factor. Asus ProArt Z490 CREATOR 10G Motherboard Maximum 128 GB DDR4 Dual Channel Memory, 4 x DDR4 DIMM attachments, Supported Bus Speed 4800/ 4600(O.C)/ 4500(O.C)/ 4400(O.C)/ 4266/ 4133/ 4000/ 3866/ 3733/ 3600/ 3466/ 3400/ 3333/ 3300/ 3200/ 3000/ 2933/ 2800/ 2666/ 2400/ 2133 MHz. Asus ProArt Z490 CREATOR Motherboard accompanies standard Graphics, for example, 1 x DisplayPort 1.4, 1 x HDMI 1.4b, Graphics particulars might fluctuate between CPU types. ProArt Z490 CREATOR Asus Motherboard Expansion PCI Slots is 1 x PCIe 3.0/4.0 x 16 openings, 2 x SATA 6 GB/s, 6 x SATA 6 GB/s, 1 x M.2_2 attachment 3, Supported Raid 0, 1, 5, 10 likewise different Internal Connectors, for example, 1 x 24-pin ATX principle power connector, 1 x 4 pin CPU fan header, 1 x M.2_FAN connector, and so forth In addition in this Asus ProArt Z490 Motherboard has Intel® I225-V 2.5Gb Ethernet, 1 x LAN (RJ45) port(s), 4 USB 3.2 Gen 1, 2 USB 2.0 ports, 5 x Audio jack(s). Additionally, The Z490 maker Motherboard has some exceptional elements like ASUS Exclusive Software.
Asus ProArt Z490 CREATOR Motherboard Support for Windows 10 64-cycle. You can appreciate 03 Years Warranty and purchase Motherboard from Original Store Ltd and get online conveyance at any side of Bangladesh.
