| Price | : | To be announced |
| Status | : | Out of Stock |
| Brand | : | Asus |
| Product Code | : | Z390M-Plus |
| General Information | ||
| Model | Asus Prime Z390M-Plus | |
| Supported Processor | Intel® Socket 1151 for 9th / 8th Generation Pentium®/Celeron® Processors | |
| Chipset | Intel® Z390 | |
| Socket | 1151 | |
| BIOS | * 128 Mb Flash ROM
* UEFI AMI BIOS
* PnP SM BIOS 3.1
* ACPI 6.1
* MultilanguageBIOS
* ASUS EZ Flash 3
* CrashFree BIOS 3
* F6 Qfan Control
* F3 MyFavorites
* Last Modified log
* F12 PrintScreen |
|
| Form Factor | mATX Form Factor 9.6-inch x 9.6 inch | |
| Memory Information | ||
| Memory Types | DDR4 | |
| Channel | Dual Channel | |
| Slot | 4 x DIMM | |
| Supported Bus Speed | 4266/ 4133/ 4000/ 3866/ 3733/ 3600/ 3466/ 3400/ 3333/ 3300/ 3200/ 3000/ 2800/ 2666/ 2400/ 2133 MHz | |
| Maximum Memory | 128GB | |
| Graphics Information | ||
| Graphics | * Integrated Graphics Processor- Intel® HD Graphics support * Multi-VGA output support: HDMI/DVI-D ports * Supports HDMI with max. resolution 4096 x 2160 @ 30 Hz * Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz * Supports Intel® InTru™ 3D, Quick Sync Video, Clear Video HD Technology, Insider |
|
| Expansion Slots | ||
| PCI | * 1 x PCIe 3.0/2.0 x16 (x16 or x8+x4+x4) * * 1 x PCIe 3.0/2.0 x16 (max at x4 mode) * 2 x PCIe 3.0/2.0 x1 |
|
| Storage Information | ||
| M.2 | * 1 x M.2 Socket 3, , with M key, type 2242/2260/2280 storage devices support * 1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support |
|
| SATA | 4 x SATA 6Gb/s port(s), gray | |
| RAID | Support Raid 0, 1, 5, 10 | |
| Connector Information | ||
| Internal Connectors | * 2 x USB 3.2 Gen 1(up to 5Gbps) connector(s) * 2 x USB 2.0 connector(s) support(s) * 1 x M.2 Socket 3 with M key * 1 x M.2 Socket 3 with M key * 1 x COM port(s) connector(s) * 4 x SATA 6Gb/s connector(s) * 1 x CPU Fan connector(s) (1 x 4 -pin) * 2 x Chassis Fan connector(s) (2 x 4 -pin) * 1 x AIO_PUMP connector (1 x 4 -pin) * 1 x S/PDIF out header(s) * 1 x 24-pin EATX Power connector(s) * 1 x 8-pin EATX 12V Power connectors * 1 x Front panel audio connector(s) (AAFP) * 1 x MemOK! II switch(es) * 1 x Clear CMOS jumper(s) * 1 x System panel connector * 1 x Mono Out header * 1 x RGB Header |
|
| Port Information | ||
| PS/2 Por | * 1 x PS/2 keyboard (purple)
* 1 x PS/2 mouse (green) |
|
| USB Port | * 2 x USB 3.2 Gen 2 Type-A
* 4 x USB 3.2 Gen 1 Type-A |
|
| HDMI Port | 1 x HDMI | |
| DVI-D Port | 1 x DVI-D | |
| LAN Port | 1 x LAN (RJ45) port(s) | |
| Audio Port | 3 x Audio jack(s) | |
| Operating System | ||
| Supported OS | Windows® 10 64-bit | |
| Warranty | ||
| Warranty | 03 Years Warranty | |
Asus Prime Z390M-Plus motherboard gives you the strong foundation you expect in your first form, in addition to the versatility of developing with your aspirations. We've put together all the cool stuff with basic planning and design in the latest Intel® Socket 1151 for 9th / 8th Generation Pentium®/Celeron® Processors support, so you can benefit from industry-driven advances, including tuning of mechanical structures. Extensive cooling control, and lively locally available sound.
For more Motherboard information Please Check Gigabyte Motherboard, MSI Motherboard, Asus Motherboard, Esonic Motherboard, and Asrock Motherboard. And also If you Want to know more different type of IT Product information please Click here.
Asus Prime Z390M-Plus motherboard comes with Intel® Socket 1151 for 9th / 8th Generation Pentium®/Celeron® Processors, 128 Mb Flash ROM, UEFI AMI BIOS, PnP SM BIOS 3.1, ACPI 6.1, MultilanguageBIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F6 Qfan Control, F3 MyFavorites, Last Modified log, F12 PrintScreen, mATX Form Factor. Dual Channel 4 x DIMM DDR4 Maximum Memory 128GB, Supported Bus Speed 4266/ 4133/ 4000/ 3866/ 3733/ 3600/ 3466/ 3400/ 3333/ 3300/ 3200/ 3000/ 2800/ 2666/ 2400/ 2133 MHz. In this Asus Prime Z390M-Plus motherboard, Integrated Graphics Processor-Intel® HD Graphics support, Multi-VGA yield support: HDMI/DVI-D ports, Supports HDMI with max. resolution 1920 x 1200 @ 60 Hz. Expansion Slots are 1 x PCIe 3.0/2.0 x16 (max at x4 mode), 2 x PCIe 3.0/2.0 x1. Also in this motherboard, Internal Connectors are 1 x M.2 Socket 3, with M key, type 2242/ 2260/ 2280/ 22110 storage devices support, 4 x SATA 6Gb/s port(s), gray, Support Raid 0, 1, 5, 10. 1 x 24-pin EATX Power connector(s), 1 x 8-pin EATX 12V Power connectors, 2 x USB 3.2 Gen 2 Type-A, 4 x USB 3.2 Gen 1 Type-A, 1 x LAN (RJ45) port(s), 3 x Audio jack(s).
Asus Prime Z390M-Plus motherboard OS Support Windows® 10 64-bit. You can enjoy a 03 Years Warranty. Purchase Motherboard from Original Store Ltd and get online conveyance at any side of Bangladesh.
