| Price | : | To be announced |
| Status | : | Out of Stock |
| Brand | : | MSI |
| Product Code | : | MPG Z590 Gaming EDGE Wi-Fi |
| General Information | ||
| Model | MPG Z590 Gaming EDGE Wi-Fi | |
| Brand | MSI | |
| Supported Processor | Supports 10th Gen Intel Core Processors, 11th Gen Intel Core Processors, Pentium Gold and Celeron Processors | |
| Chipset | Intel Z590 Chipset | |
| Socket | LGA1200 | |
| Form Factor | ATX Form Factor | |
| Memory Information | ||
| Memory Types | DDR4 | |
| Channel | Dual Channel | |
| Slot | 4x memory slots | |
| Supported Bus Speed | 5333(OC) / 5200(OC) / 5000(OC)/ 4800(OC)/ 4600(OC)/ 4533(OC)/ 4400(OC)/ 4300(OC)/ 4266(OC)/ 4200(OC)/ 4133(OC)/ 4000(OC)/ 3866(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3300(OC)/ 3200(OC)/ 3000(OC)/ 2933(JEDEC)/ 2666(JEDEC)/ 2400(JEDEC)/ 2133(JEDEC) MHz | |
| Maximum Memory | 128GB | |
| Graphics Information | ||
| Graphics | 1x HDMI 2.0b with HDR port, supports a maximum resolution of 4K 60Hz
1x DisplayPort 1.4 port, supports a maximum resolution of 4K 60Hz |
|
| Expansion Slots | ||
| PCI | 3x PCIe x16 slots
Support x16/x4/x4
PCI_E1 (From CPU)
Supports up to PCIe 4.0 for 11th Gen Intel CPU
Supports up to PCIe 3.0 for 10th Gen Intel CPU
PCI_E3 & PCI_E5 (From Z590 Chipset)
Support up to PCIe 3.0
2x PCIe 3.0 x1 slots (From Z590 Chipset) |
|
| Storage Information | ||
| M.2 | 3x M.2 slots (Key M)
M2_1 slot (From CPU)
Available only on 11th Gen Intel CPU
Supports PCIe 4.0 x4
Supports 2242/ 2260/ 2280/ 22110 storage devices
M2_2 & M2_3 slot (From Z590 Chipset)
Support up to PCIe 3.0 x4 and SATA 6Gb/s
Supports 2242/ 2260/ 2280 storage devices
Intel Optane Memory Ready |
|
| SATA | 6Gb/s | |
| Connector Information | ||
| Internal Connectors | 1x 24-pin ATX main power connector 2x 8-pin ATX 12V power connectors 1x 6-pin PCIE power connector 6x SATA 6Gb/s connectors 3x M.2 slots (M-Key) 1x USB 3.2 Gen 2 10Gbps Type-C port 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports) 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 1x 4-pin CPU fan connector 1x 4-pin water-pump fan connector 6x 4-pin system fan connectors 1x Front panel audio connector 2x System panel connectors 1x Chassis Intrusion connector 1x Clear CMOS jumper 1x TBT connector (supports RTD3) |
|
| Port Information | ||
| USB Port | Intel Z590 Chipset 1x USB3.2 Gen2x2 20Gbps port (Type-C port on the back panel) 4x USB 3.2 Gen 1 5Gbps ports (2 Type-A port on the back panel and 2 ports are available through the internal connectors) 4x USB 3.2 Gen 2 10Gbps ports (1 Type-C internal connector and 3 Type-A ports on the back panel) Hub-GL850G 6x USB 2.0 ports (2 Type-A port on the back panel and 4 ports are available through the internal connectors) |
|
| HDMI Port | 1x HDMI 2.0b with HDR port, supports a maximum resolution of 4K 60Hz | |
| LAN Port | 1x Intel® I225-V 2.5G LAN | |
| Audio Port | 5+ Optical S/PDIF (Realtek® ALC4080 Codec) | |
| Display Port | 1x DisplayPort 1.4 port, supports a maximum resolution of 4K 60Hz | |
| Special Features | ||
| WIFI | Intel® Wi-Fi 6E AX210 |
|
| Operating Systems | ||
| Supported OS | Support for Windows® 10 64-bit | |
| Warranty | ||
| Warranty | 03 Years Warranty | |
MSI MPG Z590 Gaming EDGE WIFI 10th and 11th Gen Motherboard. MSI MPG Z590 Gaming EDGE Motherboards come with an upgraded power solution, the latest storage standards, and outstanding connectivity to enable optimized performance for gaming. Buy MSI MPG Z590 Gaming EDGE Motherboard at the best price in Bangladesh.
For more Motherboard information Please Check Gigabyte Motherboard, MSI Motherboard, Asus Motherboard, Esonic Motherboard, and Asrock Motherboard. And also If you Want to know more different type of IT Product information please Click here.
MSI MPG Z590 Gaming EDGE WIFI 10th and 11th Gen Motherboard comes with Supports 10th Gen Intel Core Processors, 11th Gen Intel Core Processors, Pentium Gold and Celeron Processors 1, Intel Z590 Chipset with ATX Form Factor and LGA 1200 socket. MSI MPG Z590 Gaming EDGE WIFI Motherboard Maximum Memory 128 GB DDR4 Dual Channel Memory, 4 x DDR4 DIMM sockets, Supported Bus Speed Supports 1R 2133/ 2666/ 2933 MHz for Intel 10th Gen Processor (by JEDEC & POR)1, it is supported 1R 2133/ 2666/ 2933/ 3200 MHz for Intel 11th Gen Processor (by JEDEC & POR)1. MSI MPG Z590 Gaming EDGE Wi-Fi Intel Motherboard added with standard Graphics such as 1x HDMI 2.0b with HDR port, also, supports a maximum resolution of 4K 60Hz. MPG Z590 Gaming EDGE Wi-Fi MSI Motherboard Expansion PCI slot is 3x PCIe x16 slots, Supports up to PCIe 4.0 for 11th Gen Intel CPU, 6 x SATA 6 GB/s connectors, 3x M.2 slots also various Internal Connectors such as 1 x 24-pin ATX main power connector, 1 x 4 pin CPU fan header, 1 x front panel audio connector, etc. The MSI MPG Z590 Gaming EDGE Wi-Fi Motherboard has 2 x USB 3.2 Gen 2 10Gbps, 6x USB 2.0 ports, and 1x DisplayPort. The MSI MPG Z590 Gaming EDGE WIFI 10th and 11th Gen Motherboard Support for Windows 10 64-bit. You can enjoy 03 Years Warranty. You can buy Motherboard from Original Store Ltd and get online delivery at any corner of Bangladesh.
