| Price | : | To be announced |
| Status | : | Out of Stock |
| Brand | : | Gigabyte |
| Product Code | : | GB450AE |
| General Information | ||
| Model | Gigabyte B450 AORUS | |
| Supported Processor | AM4 Socket: AMD Ryzen 3rd Gen Ryzen/ 2nd Gen Ryzen/ 1st Gen Ryzen RadeonAthlon with Radeon Vega Graphics Processors | |
| Chipset | AMD B450 | |
| Socket | AM4 | |
| BIOS | * 1 x 128 Mbit flash * Use of licensed AMI UEFI BIOS * PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
|
| Form Factor | ATX Form Factor; 30.5cm x 23.5cm | |
| Memory Information | ||
| Memory Types | DDR4 | |
| Channel | Dual channel | |
| Slot | 4 x DDR4 memory | |
| Supported Bus Speed | 3600(O.C.)/3466(O.C.)/3200(O.C.)/2933/2667/2400/2133 MHz | |
| Maximum Memory | 128 GB | |
| Graphics Information | ||
| Graphics | * 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz * The DVI-D port does not support D-Sub connection by adapter. * 1 x HDMI port, supporting a maximum resolution of 4096x2160@60(Note) Hz * Support for HDMI 2.0 version and HDCP 2.2.(Note) |
|
| Expansion Slots | ||
| PCI | * 1 x PCI Express x16 slot, running at x16 (PCIEX16)(Note) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. (The PCIEX16 slot conforms to PCI Express 3.0 standard.) * 1 x PCI Express x16 slot, running at x4 (PCIEX4) * The PCIEX4 slot shares bandwidth with the PCIEX1_2 slot. The PCIEX4 slot operates at up to x2 mode when the PCIEX1_2 slot is populated. The PCIEX4 slot operates at up to x4 mode when the PCIEX1_2 is empty. * 2 x PCI Express x1 slots |
|
| Storage Information | ||
| M.2 | 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 3.0 x4/x2 SSD support) (M2A_SOCKET) | |
| SATA | 6 x SATA 6Gb/s connectors | |
| RAID | Support for RAID 0, RAID 1, and RAID 10 | |
| Connector Information | ||
| Internal Connectors | * 1 x 24-pin ATX main power connector * 1 x 8-pin ATX 12V power connector * 2 x M.2 Socket 3 connectors * 6 x SATA 6Gb/s connectors * 1 x CPU fan header * 3 x system fan headers * 1 x CPU cooler LED strip/RGB LED strip extension cable header * 1 x RGB (RGBW) LED strip header * 2 x digital LED strip headers * 2 x digital LED strip power select jumpers * 1 x front panel header * 1 x front panel audio header * 1 x S/PDIF Out header * 1 x USB 3.1 Gen 1 header * 2 x USB 2.0/1.1 headers * 1 x serial port header * 1 x Clear CMOS jumper |
|
| Port Information | ||
| PS/2 Port | 1 x PCI Express x16 slot, running at x16 |
|
| USB Port | * 4 x USB 3.1 Gen 1 ports * 4 x USB 2.0/1.1 ports |
|
| HDMI Port | 1 x HDMI port | |
| DVI-D Port | 1 x DVI-D port | |
| LAN Port | * Realtek® GbE LAN chip (10/100/1000 Mbit) * 1 x RJ-45 port |
|
| Audio Port | * 6 x audio jacks * Realtek® Audio CODEC |
|
| Operating System | ||
| Supported OS | Support for Windows 10,7 64-bit | |
| Warranty | ||
| Warranty | 03 Years Warranty | |
This Gigabyte B450 AORUS ELITE Motherboard comes with AMD Socket AM4, AM4 Socket: AMD Ryzen 3rd Gen Ryzen/ 2nd Gen Ryzen Radeon Athlon with Radeon Vega Graphics Processors, Chipset AMD B450, AM4 Socket, Bios is 1 x 128 Mbit flash, Use of licensed AMI UEFI BIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 and 30.5cm x 23.5cm ATX Form Factor. B450 AORUS ELITE Gigabyte Motherboard Maximum 128 GB DDR4 Dual Channel Memory, 4 x DDR4 DIMM sockets, Supported Bus Speed 3600(O.C.)/3466(O.C.)/3200(O.C.)/2933/2667/2400/2133 MHz.
Gigabyte B450 AORUS ELITE Motherboard comes with standard Graphics such as 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz, supporting a maximum resolution of 1920x1200@60 Hz, The DVI-D port does not support D-Sub connection by the adapter, Support for HDMI 1.4 version and HDCP 2.2. This Motherboard Expansion PCI Slots is 1 x PCI Express x16 slot, running at x16, 2 x PCI Express x1 slots, 6 x SATA 6 GB/s connectors and 1. 1 x M.2 connector also various Internal Connectors such as 4 x 24-pin ATX main power connector, 1 x CPU fan header, 1 x front panel audio header, etc. This Gigabyte B450 Motherboard has 5 x USB 3.2 Gen 1 ports, 6 x USB 2.0/1.1 ports, 1 x HDMI port, 1 x D-Sub port, Realtek GbE LAN chip (10/100/1000 Mbit), and High Definition Audio 6 x audio jacks.
This Gigabyte B450 AORUS ELITE Motherboard Support for Windows 10,7 64-bit. You can enjoy 03 Years Warranty. Buy Motherboard from Original Store Ltd and get online delivery at any corner of Bangladesh.
