| Special Price | : | ā§ŗ11,050 |
| Regular Price(EMI) | : | ā§ŗ12,000 |
| Status | : | In Stock |
| Brand | : | Gigabyte |
| Product Code | : | H610M H |
āĻ āĻ°ā§āĻĄāĻžāĻ° āĻāĻ°āĻžāĻ° āĻĒā§āĻ°ā§āĻŦā§ āĻāĻžāĻ¸ā§āĻāĻŽāĻžāĻ° āĻā§ā§āĻžāĻ° āĻĨā§āĻā§ āĻĒāĻŖā§āĻ¯ā§āĻ° āĻ¸ā§āĻāĻ āĻ¸āĻŽā§āĻĒāĻ°ā§āĻā§ āĻā§āĻ¨ā§ āĻ¨ā§ā§āĻžāĻ° āĻāĻ¨ā§āĻ¯ āĻ āĻ¨ā§āĻ°ā§āĻ§ āĻāĻ°āĻž āĻ¯āĻžāĻā§āĻā§āĨ¤ āĻĒā§āĻ°āĻ¯ā§āĻā§āĻ¤āĻŋ āĻĒāĻŖā§āĻ¯ā§āĻ° āĻŽā§āĻ˛ā§āĻ¯ āĻ āĻ¸ā§āĻĨāĻŋāĻ¤āĻŋāĻļā§āĻ˛ āĻšāĻā§āĻžāĻ° āĻāĻžāĻ°āĻ¨ā§ āĻ¯ā§āĻā§āĻ¨ā§ āĻŽā§āĻšā§āĻ°ā§āĻ¤ā§ āĻŽā§āĻ˛ā§āĻ¯ āĻĒāĻ°āĻŋāĻŦāĻ°ā§āĻ¤āĻ¨ āĻšāĻ¤ā§ āĻĒāĻžāĻ°ā§āĨ¤
| General Information | ||
| Model | H610M H | |
| Brand | Gigabyte | |
| Supported Processor | Support for 12th Generation IntelÂŽ Coreâĸ i9/ i7 / i5 processorsL3 cache varies with CPU | |
| Chipset | Intel H610 Express Chipset | |
| Socket | LGA1700 | |
| BIOS | 1 x 256 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
|
| Form Factor | Micro ATX Form Factor; 23.0cm x 21.5cm | |
| Memory Information | ||
| Memory Type | DDR4 | |
| Channel | Dual-channel | |
| Slot | 4 x DDR DIMM | |
| Supported Bus Speed | Support for DDR4 3200/3000/2933/2666/2400/2133 MHz memory modules | |
| Maximum Memory | Up to 128 GB | |
| Graphics Information | ||
| Graphics | Integrated Graphics Processor-IntelÂŽ HD Graphics support: 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.1 version and HDCP 2.3. ** Support native HDMI 2.1 TMDS compatible ports |
|
| Expansion Slots | ||
| PCI | 1 x PCI Express x16 slot, running at x16
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
(The PCI Express x16 slot conforms to PCI Express 4.0 standard.) 1 x PCI Express x1 slot
(The PCI Express x1 slot conforms to PCI Express 3.0 standard.) |
|
| Storage Information | ||
| M.2 | 1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe 3.0 x4/x2 SSD support) | |
| SATA | 4 x SATA 6Gb/s connectors | |
| Connector Information | ||
| Internal Connectors | 1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x M.2 Socket 3 connector
4 x SATA 6Gb/s connectors
1 x CPU fan header
2 x system fan headers
1 x RGB LED strip header
1 x front panel header
1 x front panel audio header
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
1 x serial port header
1 x Clear CMOS jumper |
|
| Port Information | ||
| PS/2 Port | 1 x PS/2 keyboard & mouse combo port | |
| USB Port | 2 x USB 3.2 Gen 1 ports
4 x USB 2.0/1.1 ports |
|
| HDMI Port | 1 x HDMI 2.0 port | |
| Display Port | 1 x DisplayPort | |
| D-Sub | 1 x D-Sub port | |
| DVI-D | 1 x DVI-D port | |
| LAN Port | 1 x RJ-45 port
IntelÂŽ GbE LAN chip (1 Gbps/100 Mbps) |
|
| Audio Jack | 3 x audio jacks | |
| Operating System | ||
| Supported OS | Support for Windows 11 64-bit
Support for Windows 10 64-bit |
|
| Warranty | ||
| Warranty | 03 Years | |
The Gigabyte H610M H DDR4 12th Gen Micro Atx Motherboard. Its delivery and dominant thermal design, are glorified with the complete memory overclocking technology to crown your PC with the best Alder Lake performance in all its gaming glory. It ensures maximum Turbo Boost and overclocking performance of Intel's new generation CPU. Buy Gigabyte H610M H DDR4 12th Gen Micro Atx Motherboard at the best price in BD.
For more Motherboard information Please Check Gigabyte Motherboard, MSI Motherboard, Asus Motherboard, Esonic Motherboard, and Asrock Motherboard. And also If you Want to know more different type of IT Product information please Click here.
Gigabyte H610M H DDR4 12th Gen Micro Atx Motherboard. The model is H610M H. The Brand is Gigabyte. The Motherboard Supported Processor Support for 12th Generation IntelÂŽ Coreâĸ i9/ i7 / i5 processorsL3 cache varies with CPU. Intel H610 Express Chipset. Socket LGA1700. BIOS 1 x 256 Mbit flash, Use of licensed AMI UEFI BIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0. Micro ATX Form Factor; 23.0cm x 21.5cm. Memory Type DDR4. Dual-Channel. Slot 4 x DDR DIMM. Supported Bus Speed Support for DDR4 3200/3000/2933/2666/2400/2133 MHz memory modules. Maximum Memory Up to 128 GB. Graphics Integrated Graphics Processor-IntelÂŽ HD Graphics support: 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz, 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz, Support for HDMI 2.1 version and HDCP 2.3. Support native HDMI 2.1 TMDS compatible ports. PCI 1 x PCI Express x16 slot, running at x16, For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. (The PCI Express x16 slot conforms to PCI Express 4.0 standard.) 1 x PCI Express x1 slot. (The PCI Express x1 slot conforms to PCI Express 3.0 standard.). 1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe 3.0 x4/x2 SSD support), 4 x SATA 6Gb/s connectors. Internal Connectors 1 x 24-pin m-atx main power connector, 1 x 8-pin m-atx 12V power connector, 1 x M.2 Socket 3 connector, 4 x SATA 6Gb/s connectors, 1 x CPU fan header, 2 x system fan headers, 1 x RGB LED strip header, 1 x front panel header, 1 x front panel audio header, 1 x USB 3.2 Gen 1 header, 2 x USB 2.0/1.1 headers, 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only), 1 x serial port header, 1 x Clear CMOS jumper. 1 x PS/2 keyboard & mouse combo port, 2 x USB 3.2 Gen 1 ports, 4 x USB 2.0/1.1 ports, 1 x HDMI 2.0 port, 1 x DisplayPort, 1 x D-Sub port, 1 x DVI-D port, 1 x RJ-45 port, Realtek GbE LAN chip (1 Gbps/100 Mbps), 3 x audio jacks. Support for Windows 11 64-bit and Windows 10 64-bit. Gigabyte H610M H DDR4 12th Gen Micro Atx Motherboard has Three years warranty.
